3yrs Lifetime Small Bluetooth Beacon Ble Asset Tag with Tamper-proof Button and Accelemeter Sensor
Bluetooth BLE tag based on BLE technology .widely used in asset tracking and management , and can also be used as a Bluetooth badge to manage personnel. and can be fixed on the asset surface with 3M glue. The ble asset tag has a button anti-tampering function, which can ensure the safety of assets. Once the Bluetooth tag is removed, the Bluetooth tag will immediately broadcast a removal alarm signal . The ble tracking tag integrates a three-axis acceleration sensor, which can determine whether assets or personnel are in motion.
Overview
HCBB07 is a Bluetooth BLE tag based on Bluetooth BLE technology . There are standard type (excluding key anti-tamper function) HCBB07, key anti-tamper type HCBB07-K, key anti-tamper + acceleration type HCBB07-KA. HCBB07 can be used with the Bluetooth gateway of HoneyComm IoT Technology(Shenzhen）Co.,Ltd. The product is widely used in asset tracking and management , and can also be used as a Bluetooth badge to manage personnel .
HCBB07 series products adopt low-power Bluetooth technology, low power consumption, long use time, small product size, and can be fixed on the asset surface with 3M glue. HCBB07 -K has a button anti-tampering function, which can ensure the safety of assets. Once the Bluetooth tag is removed, the Bluetooth tag will immediately broadcast a removal alarm signal . HCBB07-KA integrates a three-axis acceleration sensor, which can determine whether assets or personnel are in motion.
Features
▶ Replaceable battery:CR2032 Coin Battery
▶ Three Versions: without key anti-tampering, with key anti-tampering only, with key anti-tampering and accelemeter sensor etc.
▶ Broadcasting distance up to 70 meters ( 0dBm broadcast )
▶ Beacon parameters can be flexibly configured through APP ( when the broadcast interval is less than 1s )
▶ BLE4.2 protocol
▶ Ultra-low power consumption, standby time up to 3 years ( 0dBm transmit power, 10s broadcast interval )
▶ Small and lightweight:9.3g
▶ Easy installation: 3M Glue
Parameters
| physical properties | ||
| Part Number | HCBB07 : Without tamper function
HCBB07-K : key tamper HCBB07-KA : key tamper + acceleration |
|
| shell material | ABS | |
| shell color | Black (default), other colors can be customized (batch order not less than 3K) | |
| Dimensions | 25*44*5. 7 mm ( without 3M glue, the thickness is 5.8mm with 3M glue ) | |
| battery model | CR2032, 225mAh ( replaceable battery ) | |
| supply voltage | DC 3V | |
| installation method | 3M double-sided tape | |
| Specifications | ||
| communication method | BLE4.2 | |
| Operating mode | Broadcasting data | |
| transmit power | -30~+4dB, default 0dB | |
| broadcast interval | 100ms~10s, default 3s | |
| working frequency | 2400MHz-2483.5MHz | |
| Transmission distance | The open limit transmission distance is 70 meters (0dBm) | |
| safety | Support password connection ( when the broadcast interval is less than 1s ) and non-connectable mode, anti-malicious connection function | |
| System Requirement | IOS7.0 and above, Android 4.3 and above | |
| electrical characteristics | ||
| Quiescent Current | <=3uA | |
| peak current | 7 mA | |
| average current | <7 uA (0dB/3s)
<3 uA (0dB/10s) Remarks: Depending on the software and firmware, whether there is a response packet (with a broadcast Bluetooth name), whether it can be connected, and the current are slightly different. |
|
| using electric | CR2032 (replaceable battery) | |
| battery capacity | 2 25mAh | |
| length of work | 3 years (0dB/10s) | |
| other | ||
| use environment | Working temperature: -20℃~+ 70 ℃ | |
| Storage temperature: -20℃~+ 70 ℃ | ||
| Working humidity: 10%~90% (non-condensing state) | ||
| Storage humidity: 5%~90% (non-condensing state) | ||
